AC50/60Hz 65a 3p 220v electrical ac contactor

Product Description



Please Attention


Product Description



APPLICATION

----------------------------------------------------------------------------------------------------------------------------------------------------------------------------

LC1-D Series AC Contactor is suitable for using in the circuits up to the rated vltage 660v ac 50/60hz rated current up to 95a,for making ,frequently starting and machine interlocking device,it becomes the delay the contactor,mechanical interlocking contactor star-delta starter,with the Thermal Relay , it is combined into the eletromagnetic starter.the contactor is roduced according to IEC947-2,VDE 0660&BS5452.



SPECIFICATION

----------------------------------------------------------------------------------------------------------------------------------------------------------------------------



Type LC1-D09 LC1-D12 LC1-D18 LC1-D25 LC1-D32 LC1-D40 LC1-D50 LC1-D65 LC1-D80 LC1-D95
Rated workingcurrent (A) AC3 9 12 18 25 32 40 50 65 80 95
AC4 3.5 5 7.7 8.5 12 18.5 24 28 37 44
Standardpower ratingsof 3-phase motors 50/60Hz incategory AC-3 220/230V 2.2 3 4 5.5 7.5 11 15 18.5 22 25
380/400V 4 5.5 7.5 11 15 18.5 22 30 37 45
415V 4 5.5 9 11 15 22 25 37 45 45
500V 5.5 7.5 10 15 18.5 22 30 37 55 55
660/690V 5.5 7.5 10 15 18.5 30 33 37 45 55
Rated heat current (A) 20 20 32 40 50 60 80 80 125 125
Electrical life AC3 (x104) 100 100 100 100 80 80 60 60 60 60
AC4 (x104) 20 20 20 20 20 15 15 15 10 10
Mechanical life (x104) 1000 1000 1000 1000 800 800 800 800 600 600
Number of the contacts 3P+NO 3P+NC+NO
3P+NC

Free Sample


Certifications


World-wide Customers


Hot Products


About Us&Exhibition


Packing&FAQ





Contact us if you need more details on 220v Electrical Ac Contactor. We are ready to answer your questions on packaging, logistics, certification or any other aspects about 65a 3p 220v Electrical Ac Contactor、Ac Contactor. If these products fail to match your need, please contact us and we would like to provide relevant information.
