Free Sample Factory Price LC1-D1810 AC Contactor 36V CJX2 18 Types of AC Magnetic Contactor

Product Description

APPLICATION
LC1-D09 AC Contactor is suitable for using in the circuits up to the rated voltage 660v,AC 50hz or 60hz,rated current up to 95A,for making ,breaking frequently starting &machine-interlocking device etc,it becomes the dalay contactor,mechanical interlocking contactor,star-delta  starter.with the Thermal Relay,it is combined into the electromagnetic starter.The contactor is produced according to IEC947-2,VDE0660&BS5442.
SPECIFICATION
Type LC1-D09 LC1-D12 LC1-D18 LC1-D25 LC1-D32 LC1-D40 LC1-D50 LC1-D65 LC1-D80 LC1-D95
Rated workingcurrent(A) AC3 9 12 18 25 32 40 50 65 80 95
AC4 3.5 5 7.7 8.5 12 18.5 24 28 37 44
Standardpower ratingsof 3-phase motors 50/60Hz incategory AC-3 220/230V 2.2 3 4 5.5 7.5 11 15 18.5 22 25
380/400V 4 5.5 7.5 11 15 18.5 22 30 37 45
415V 4 5.5 9 11 15 22 25 37 45 45
500V 5.5 7.5 10 15 18.5 22 30 37 55 55
660/690V 5.5 7.5 10 15 18.5 30 33 37 45 55
Rated heat current (A) 20 20 32 40 50 60 80 80 125 125
Electrical life AC3 (x104) 100 100 100 100 80 80 60 60 60 60
AC4 (x104) 20 20 20 20 20 15 15 15 10 10
Mechanical life (x104) 1000 1000 1000 1000 800 800 800 800 600 600
Number of the contacts 3P+NO 3P+NC+NO
3P+NC






Contact us if you need more details on Ac Contactor. We are ready to answer your questions on packaging, logistics, certification or any other aspects about LC1-D1810 AC Contactor、AC Contactor 36V. If these products fail to match your need, please contact us and we would like to provide relevant information.
